Metriso B530 Test Kit
페이지 정보
본문
| General information | Metriso® B530 - test kit. Suitable for resistance point-to-point and resistance to ground measurements | ||
|---|---|---|---|
| Technical data | Test voltage / Test current: 1 mA < I < 1,3 mA ◦ High ohmic range: DC 10 volts,100 volts and 500 volts • Test range: ◦ low ohmic range: 1 to 10 kOhm ◦ high ohmic range: 1 kOhm to 199 GOhm • Operation: Battery operated • Probes: ◦ 2x Model 870 (weight: 2,27 kg / ø 63,5 mm) with conductive rubber (grey) and extension, ◦ 1x hand-held probe Model 45 • complies with IEC 61340-4-1, IEC 61340-2-3, IEC 61340-4-5 |
||
| Delivery range | • digital high resistance tester • 2 probes model 870 with extension • a hand-held probe with connecting cable • user's instructions in German, English and French • calibration certificate • conductive carrying case fitted with dissipative pink foam |
||
