EFM51 Working Test Kit
페이지 정보
본문
| General information | EFM®51 with conductive base and the measuring head MK51. By mounting the measuring head MK51 the EFM®51 can be used for verification measurement of body voltage (walking test) according to IEC 61340-4-5. The measuring head MK51 is specially calibrated for using the EFM 51. The EFM®51 shows the positive and negative "PEAK" value of the measured body voltage. |
||
|---|---|---|---|
| Technical data | • Test method: Rotating chopper • Test range: 0 V - ± 160 kV distance mode 0 - 800 kV/m Field strength mode • Display: LCD display • Operation: Battery operated |
||
| Delivery range | • EFM®51 with measuring head MK51 in conductive carrying case • conductive base • test lead • hand electrode • battery charger for 9 V batteries • spare 9V rechargeable battery |
||
EFM51 Working Test Kit
